| Číslo dielu | M195RTN01.0 |
| Značka | AUO |
| Veľkosť | 19.5 |
| Aplikácia | DMPC |
| Rozhodnutie | 1600×900 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | AUO |
| panelový model | M195RTN01.0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 19.5 inch |
| rozhodnutie | 1600(RGB)×900 , HD+ |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 433.92×236.34 mm |
| obrys | 452×263×11 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Doba odozvy | 3.8/1.2 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 10S4PWLEDWithout Driver |
| signálové rozhranie | LVDS (2 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
| LM195WD1-TLA1 | LG Display | 19.5 | 1600×900 |
| LM195WD1-TLC1 | LG Display | 19.5 | 1600×900 |
| LM195WD2-SLA1 | LG Display | 19.5 | 1600×900 |
| M195FGE-L20 | Innolux | 19.5 | 1600×900 |
| M195RTN01.0 | AUO | 19.5 | 1600×900 |
| M200HJJ-L20 | Innolux | 19.5 | 1920×1080 |
| M200HJJ-P01 | Innolux | 19.5 | 1920×1080 |
| MV195WGM-N10 | BOE | 19.5 | 1440×900 |
| A260J2-001 | Innolux | 25.5 | 1920×1200 |
| LM230WFA-SLZ1 | LG Display | 23.0 | 1920×1080 |
| LQ150X1LCD3 | SHARP | 15.0 | 1024×768 |
| LTM190BT07 | Samsung | 19.0 | 1440×900 |
| LTM220M1-L02(Glare) | Samsung | 22.0 | 1680×1050 |
| LTM340YP01 | Samsung | 34 | 3440×1440 |
| M185XW01 V2 | AUO | 18.5 | 1366×768 |
| M236H1-L07 | Innolux | 23.6 | 1920×1080 |
| M240HW01 VC | AUO | 24.0 | 1920×1080 |
| MV195WGM-N10 | BOE | 19.5 | 1440×900 |
