| Číslo dielu | M070SWP1 R4 |
| Značka | IVO |
| Veľkosť | 7.0 |
| Aplikácia | IA |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 500 |
| CR | 500:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | IVO |
| panelový model | M070SWP1 R4 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 153.6×86.64 mm |
| obrys | 165×104×5.3 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 500 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193150% |
| Doba odozvy | 16 (Typ.)(Tr+Td) |
| pozorovací uhol | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 8S2PWLEDWithout Driver |
| signálové rozhranie | TTL (1 ch, 8-bit), 60 pins |
| vstupné napätie | 3.3/10.4/22/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikácie | IA |
