| Číslo dielu | LTD121EC5V |
| Značka | TOSHIBA |
| Veľkosť | 12.1 |
| Aplikácia | NBPC |
| Rozhodnutie | 1024×768 |
| Zloženie | LCM |
| Jas | 180 |
| CR | 150:1 |
| Farby | 262K |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | Toshiba Matsushita |
| panelový model | LTD121EC5V 6 Compatible model |
| typ panelu | LTPS TFT-LCD , LCM |
| veľkosť panelu | 12.1 inch |
| rozhodnutie | 1024(RGB)×768 , XGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 245.76×184.32 mm |
| obrys | 261×199×5 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 180 cd/m² (Typ.) |
| kontrastný pomer | 150:1 (Min.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 50 (Max.)(Tr+Td) |
| pozorovací uhol | 30/30/10/20 (Min.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (1 ch, 6-bit), 20 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NBPC |
