| Číslo dielu | LTA460HQ20-C01 |
| Značka | Samsung |
| Veľkosť | 46 |
| Aplikácia | LCTV |
| Rozhodnutie | 1920×1080 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 4000:1 |
| Farby | 1.07B |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | SAMSUNG |
| panelový model | LTA460HQ20-C01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 46 inch |
| rozhodnutie | 1920(RGB)×1080 , FHD |
| režim zobrazenia | SVA, Normally Black, Transmissive |
| aktívna oblasť | 1018.08×572.67 mm |
| obrys | 1045.9×602.1×34.2 mm |
| povrch | Glare (Haze 0%) |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 4000:1 (Typ.) |
| zobraziť farby | 1.07B (8-bit + Dithering), CIE193170% |
| Doba odozvy | 6 (Typ.)(G to G) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 120Hz (60Hz Input) |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (2 ch, 10-bit), 51 pins |
| vstupné napätie | 12.0V (Typ.) |
| aplikácie | LCTV |
