| Číslo dielu | LT085AC18N00 |
| Značka | TOSHIBA |
| Veľkosť | 8.5 |
| Aplikácia | IA |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | |
| CR | 300:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | Toshiba Mobile Display |
| panelový model | LT085AC18N00 |
| typ panelu | LTPS TFT-LCD , LCM |
| veľkosť panelu | 8.5 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 184.8×110.88 mm |
| povrch | |
| jas | |
| kontrastný pomer | 300:1 (Typ.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 50/50 (Max.)(Tr/Td) |
| pozorovací uhol | 55/55/60/35 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | WLEDWithout Driver |
| signálové rozhranie | CMOS (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| rohs: | |
| aplikácie | IA |
