| Číslo dielu | LQ150X1LGN2C |
| Značka | SHARP |
| Veľkosť | 15.0 |
| Aplikácia | |
| Rozhodnutie | 1024×768 |
| Zloženie | LCM |
| Jas | 260 |
| CR | 350:1 |
| Farby | 16.2M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | SHARP |
| panelový model | LQ150X1LGN2C |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 15.0 inch |
| rozhodnutie | 1024(RGB)×768 , XGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 304.128×228.096 mm |
| obrys | 326×252×11.5 mm |
| povrch | Antiglare (Haze 28%), Hard coating (2H) |
| jas | 260 cd/m² (Typ.) |
| kontrastný pomer | 350:1 (Typ.) |
| zobraziť farby | 16.2M (6-bit + FRC) |
| Doba odozvy | 16 (Typ.)(Tr+Td) |
| pozorovací uhol | 60/60/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (1 ch, 8-bit), 20 pins |
| vstupné napätie | 3.3V (Typ.) |
