| Číslo dielu | LQ150X1DWF1 |
| Značka | SHARP |
| Veľkosť | 15.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 1024×768 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 400:1 |
| Farby | 262K |
| Podsvietenie | CCFL |
| Rozhranie | TTL |
| značka panelu | SHARP |
| panelový model | LQ150X1DWF1 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 15.0 inch |
| rozhodnutie | 1024(RGB)×768 , XGA |
| režim zobrazenia | MVA, Normally Black, Transmissive |
| aktívna oblasť | 304.128×228.096 mm |
| obrys | 347.3×263.5×16.8 mm |
| povrch | Antiglare (Haze 25%), Hard coating (2H) |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Typ.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 15/10 (Typ.)(Tr/Td) |
| pozorovací uhol | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhranie | CMOS/TTL (2 ch, 6-bit), 60 pins |
| vstupné napätie | 5.0V (Typ.)(VCC) |
| aplikácie | DMPC |
