| Číslo dielu | LQ12S41 |
| Značka | SHARP |
| Veľkosť | 12.1 |
| Aplikácia | IA |
| Rozhodnutie | 800×600 |
| Zloženie | LCM |
| Jas | 270 |
| CR | 150:1 |
| Farby | 262K |
| Podsvietenie | CCFL |
| Rozhranie | TTL |
| značka panelu | SHARP |
| panelový model | LQ12S41 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 12.1 inch |
| rozhodnutie | 800(RGB)×600 , SVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 246×184.5 mm |
| obrys | 290×225×13.7 mm |
| povrch | Antiglare (Haze 28%), Hard coating (3H) |
| jas | 270 cd/m² (Typ.) |
| kontrastný pomer | 150:1 (Min.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 20/40 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/55/55 (Min.)(CR≥5)(L/R/U/D) |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 6-bit), 41 pins |
| vstupné napätie | 3.3V (Typ.)(VCC) |
| aplikácie | IA |
