| Číslo dielu | LQ057AC111 |
| Značka | Other |
| Veľkosť | 5.7 |
| Aplikácia | IA |
| Rozhodnutie | 320×240 |
| Zloženie | LCM |
| Jas | 350 |
| CR | 200:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | Parallel/Serial |
| značka panelu | CHILIN |
| panelový model | LQ057AC111 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 5.7 inch |
| rozhodnutie | 320(RGB)×240 , QVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 115.2×86.4 mm |
| obrys | 126×101.55 mm |
| povrch | Antiglare |
| jas | 350 cd/m² (Typ.) |
| kontrastný pomer | 200:1 (Typ.) |
| zobraziť farby | 16.7M |
| Doba odozvy | 15/35 (Typ.)(Tr/Td) |
| pozorovací uhol | 65/65/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 3S7PWLEDWithout Driver |
| signálové rozhranie | Digital RGB (8/24-bit), CCIR601/656, 50 pins |
| vstupné napätie | 3.3/5.0V (Typ.)(VDD/AVDD) |
| aplikácie | IA |
