| Číslo dielu | LQ050T3GG01 |
| Značka | SHARP |
| Veľkosť | 5.0 |
| Aplikácia | PDVD |
| Rozhodnutie | 400×234 |
| Zloženie | LCM |
| Jas | 350 |
| CR | 60:1 |
| Farby | Full color |
| Podsvietenie | CCFL |
| Rozhranie | Analog |
| značka panelu | SHARP |
| panelový model | LQ050T3GG01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 5.0 inch |
| rozhodnutie | 400(RGB)×234 |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 111.6×62.9 mm |
| obrys | 127.7×80.8×7.6 mm |
| povrch | |
| jas | 350 cd/m² (Typ.) |
| kontrastný pomer | 60:1 (Min.) |
| zobraziť farby | Full color |
| Doba odozvy | 30/50 (Typ.)(Tr/Td) |
| pozorovací uhol | 65/65/40/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhranie | TFT Specific Analog RGB, 32 pins |
| vstupné napätie | 5.3/10.9/13.0/-10.0V (Typ.)(VSH/VCC/VGH/VGL) |
| aplikácie | PDVD |
