| Číslo dielu | LP140WD2-TLB1 |
| Značka | LG Display |
| Veľkosť | 14.0 |
| Aplikácia | NBPC |
| Rozhodnutie | 1600×900 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 350:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | LG Display |
| panelový model | LP140WD2-TLB1 4 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 14.0 inch |
| rozhodnutie | 1600(RGB)×900 , HD+ |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 309.12×173.88 mm |
| obrys | 320.4×204.6×3.6 mm |
| tvarový štýl | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| povrch | Antiglare, Hard coating (3H) |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 350:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193145% |
| Doba odozvy | 16 (Typ.)(Tr+Td) |
| pozorovací uhol | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (2 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NBPC |
