| Číslo dielu | LM240WU5-SLA4 |
| Značka | LG Display |
| Veľkosť | 24.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 1920×1200 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 1000:1 |
| Farby | 1.07B |
| Podsvietenie | RGB LED |
| Rozhranie | LVDS |
| značka panelu | LG.Philips LCD |
| panelový model | LM240WU5-SLA4 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 24.0 inch |
| rozhodnutie | 1920(RGB)×1200 , WUXGA |
| režim zobrazenia | S-IPS, Normally Black, Transmissive |
| aktívna oblasť | 518.4×324 mm |
| obrys | 546.4×352×48.9 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 1.07B (10-bit), CIE1931110% |
| Doba odozvy | 6/6 (Typ.)(Tr/Td); 6 (Typ.)(G to G) |
| pozorovací uhol | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | RGB LEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (2 ch, 10-bit), 51 pins |
| vstupné napätie | 12.0V (Typ.) |
| aplikácie | DMPC |
