| Číslo dielu | LD050WV1-SP01 |
| Značka | LG Display |
| Veľkosť | 5.0 |
| Aplikácia | UMPC |
| Rozhodnutie | 480×800 |
| Zloženie | LCM |
| Jas | 500 |
| CR | 700:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | LG Display |
| panelový model | LD050WV1-SP01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 5.0 inch |
| rozhodnutie | 480(RGB)×800 , WVGA |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 64.8×108 mm |
| obrys | 71.4×120.4×4.31 mm |
| povrch | Antiglare |
| jas | 500 cd/m² (Typ.) |
| kontrastný pomer | 700:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 30 (Typ.)(Tr+Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 5S2PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 8-bit) + SPI, 40 pins |
| vstupné napätie | 2.9V (Typ.) |
| aplikácie | UMPC |
