| Číslo dielu | LB048WV1-TL01 |
| Značka | LG Display |
| Veľkosť | 4.8 |
| Aplikácia | UMPC |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 280 |
| CR | 350:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | LG.Philips LCD |
| panelový model | LB048WV1-TL01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 4.8 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 103.8×62.28 mm |
| obrys | 114.65×74.7×5.88 mm |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 280 cd/m² (Typ.) |
| kontrastný pomer | 350:1 (Typ.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 16 (Typ.)(Tr+Td) |
| pozorovací uhol | 65/65/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 6S2PWLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 6-bit), 30 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | UMPC |
