| Číslo dielu | HV320WX2-201 |
| Značka | BOE |
| Veľkosť | 31.5 |
| Aplikácia | LCTV |
| Rozhodnutie | 1366×768 |
| Zloženie | CELL |
| Jas | 0 |
| CR | 1200:1 |
| Farby | 16.7M |
| Podsvietenie | No B/L |
| Rozhranie | LVDS |
| značka panelu | BOE |
| panelový model | HV320WX2-201 |
| typ panelu | a-Si TFT-LCD , CELL |
| veľkosť panelu | 31.5 inch |
| rozhodnutie | 1366(RGB)×768 , WXGA |
| režim zobrazenia | AFFS, Normally Black, Transmissive |
| aktívna oblasť | 697.685×392.256 mm |
| obrys | 716×408.6 mm |
| povrch | Antiglare (Haze 10%), Hard coating (3H) |
| hĺbka skla | 0.70+0.70 mm |
| priepustnosť | 6.6% (Typ.)(with Polarizer) |
| kontrastný pomer | 1200:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 8 (Typ.)(G to G) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| signálové rozhranie | LVDS (1 ch, 8-bit), 30 pins |
| vstupné napätie | 12.0V (Typ.) |
| aplikácie | LCTV |
