| Číslo dielu | HSD123JPW3-A10 |
| Značka | HannStar |
| Veľkosť | 12.3 |
| Aplikácia | Outdoor High Brightn |
| Rozhodnutie | 1920×720 |
| Zloženie | LCM, a-Si TFT-LCD |
| Jas | |
| CR | 1500:1 |
| Farby | 16.7M |
| Podsvietenie | 11S4P |
| Rozhranie | LVDS |
| výrobca | HannStar |
| meno modela | HSD123JPW3-A10 |
| veľkosť obrazovky | 12.3 inch |
| typ obrazovky | LCM, a-Si TFT-LCD |
| počet pixelov | 1920(RGB)×720 167PPI |
| usporiadanie | RGB Vertical Stripe |
| aktívna plocha (mm) | 292.032 × 109.512 (H×V) |
| obrys (mm) | 302 × 125.4 × 14.2 (H×V×D) |
| plocha rámu (mm) | - |
| liečbe | Glare (Haze 0%), Hard coating |
| jas | 850 cd/m² (Typ.) |
| kontrastný pomer | 1500 : 1 (Typ.) (TM) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10) |
| odpoveď | 25 (Typ.)(Tr+Td) ms |
| dobrý výhľad na | Symmetry |
| pracovný režim | IPS Pro, Normally Black, Transmissive |
| farebná hĺbka | 16.7M 75% NTSC |
| podsvietenie | 11S4P WLED , 30K hours , No Driver |
| omša | 345/378g (Typ./Max.) |
| používa | Outdoor High Brightness Automotive Display |
| obnovovacia frekvencia | 60Hz |
| dotyková obrazovka | Without |
| typ signálu | LVDS (2 ch, 8-bit) , Connector 50 pins |
| napájací zdroj | 3.3V (Typ.) |
| max. hodnotenia | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
