| Číslo dielu | G057VGE-T01 |
| Značka | Innolux |
| Veľkosť | 5.7 |
| Aplikácia | IA |
| Rozhodnutie | 640×480 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 800:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | INNOLUX |
| panelový model | G057VGE-T01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 5.7 inch |
| rozhodnutie | 640(RGB)×480 , VGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 115.2×86.4 mm |
| obrys | 144×104.6×12.8 mm |
| povrch | Antiglare (Haze 25%) |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193154% |
| Doba odozvy | 15/35 (Typ.)(Tr/Td) |
| pozorovací uhol | 80/80/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | TTL (1 ch, 6-bit), 33 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | IA |
