| Číslo dielu | B173RW01 V0 |
| Značka | AUO |
| Veľkosť | 17.3 |
| Aplikácia | NBPC |
| Rozhodnutie | 1600×900 |
| Zloženie | LCM |
| Jas | 220 |
| CR | 500:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | AUO |
| panelový model | B173RW01 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 17.3 inch |
| rozhodnutie | 1600(RGB)×900 , HD+ |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 382.08×214.92 mm |
| obrys | 398.1×232.8×5.8 mm |
| tvarový štýl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 220 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193160% |
| Doba odozvy | 2/6 (Typ.)(Tr/Td) |
| pozorovací uhol | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (2 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NBPC |
| B173RW01 V0 | AUO | 17.3 | 1600×900 |
| B173RW01 V1 | AUO | 17.3 | 1600×900 |
| B173RW01 V2 HW7A | AUO | 17.3 | 1600×900 |
| B173RW01 V3 | AUO | 17.3 | 1600×900 |
| B173RW01 V5 | AUO | 17.3 | 1600×900 |
| HSD173PUW1-A01 | HannStar | 17.3 | 1920×1080 |
| LP173WF1-TLB3 | LG Display | 17.3 | 1920×1080 |
| LTN173HT02-C01 | Samsung | 17.3 | 1920×1080 |
| N173HCE-E31 | Innolux | 17.3 | 1920×1080 |
| N173HGE-E11 | Innolux | 17.3 | 1920×1080 |
| BT140GW03 V.2 | Innolux | 14.0 | 1366×768 |
| LP140WH2-TLF3 | LG Display | 14.0 | 1366×768 |
| LP156WHA-SLA2 | LG Display | 15.6 | 1366×768 |
| LTD121ECBP | TOSHIBA | 12.1 | 1024×768 |
| LTD121EXSF | TOSHIBA | 12.1 | 1280×800 |
| LTN121AT01-002 | Samsung | 12.1 | 1280×800 |
| LTN125AT03-803 | Samsung | 12.5 | 1366×768 |
| LTN133AT05-001 | Samsung | 13.3 | 1280×800 |
| LTN141AT16-B03 | Samsung | 14.1 | 1280×800 |
| N133BGE-LB1 | Innolux | 13.3 | 1366×768 |
