| Číslo dielu | B156XW02 V0 |
| Značka | AUO |
| Veľkosť | 15.6 |
| Aplikácia | NBPC |
| Rozhodnutie | 1366×768 |
| Zloženie | LCM |
| Jas | 220 |
| CR | 500:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | AUO |
| panelový model | B156XW02 V0 61 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 15.6 inch |
| rozhodnutie | 1366(RGB)×768 , WXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 344.232×193.536 mm |
| obrys | 359.3×209.5×5.5 mm |
| tvarový štýl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| povrch | Glare (Haze 0%), Hard coating (3H), Reflection 5.0% (Max.) |
| jas | 220 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193160% |
| Doba odozvy | 6/2 (Typ.)(Tr/Td) |
| pozorovací uhol | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 9S6PWLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NBPC |
| B156XTN02.0 | AUO | 15.6 | 1366×768 |
| B156XTN02.4 | AUO | 15.6 | 1366×768 |
| B156XTN03.1 | AUO | 15.6 | 1366×768 |
| B156XW01 V1 | AUO | 15.6 | 1366×768 |
| B156XW02 V3 | AUO | 15.6 | 1366×768 |
| B156XW02 V6 | AUO | 15.6 | 1366×768 |
| B156XW03 V1 | AUO | 15.6 | 1366×768 |
| B156XW03 V2 | AUO | 15.6 | 1366×768 |
| B156XW04 V0 | AUO | 15.6 | 1366×768 |
| B156XW04 V5 | AUO | 15.6 | 1366×768 |
| B121EW09 V2 | AUO | 12.1 | 1280×800 |
| CLAA154WB08AN | CPT | 15.4 | 1280×800 |
| HT141WXB-100 | BOE | 14.1 | 1280×800 |
| LP133WX3-TLA6 | LG Display | 13.3 | 1280×800 |
| LP173WD1-TLD3 | LG Display | 17.3 | 1600×900 |
| LTN121X1-L02 | Samsung | 12.1 | 1024×768 |
| LTN121XJ-L07 | Samsung | 12.1 | 1024×768 |
| LTN160AT06-B01 | Samsung | 16.0 | 1366×768 |
| M125NWR2 R1 | IVO | 12.5 | 1366×768 |
| N133HSE-EA3 | Innolux | 13.3 | 1920×1080 |
