| Číslo dielu | B116XW05 V004 |
| Značka | AUO |
| Veľkosť | 11.6 |
| Aplikácia | NOPC |
| Rozhodnutie | 1366×768 |
| Zloženie | CELL |
| Jas | 0 |
| CR | 700:1 |
| Farby | 262K |
| Podsvietenie | No B/L |
| Rozhranie | eDP |
| značka panelu | AUO |
| panelový model | B116XW05 V004 |
| typ panelu | a-Si TFT-LCD , CELL |
| veľkosť panelu | 11.6 inch |
| rozhodnutie | 1366(RGB)×768 , WXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 256.125×144 mm |
| obrys | 289.34×155.9 mm |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| hĺbka skla | 0.30+0.30 mm |
| priepustnosť | 5.3% (Typ.)(with Polarizer) |
| kontrastný pomer | 700:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193145% |
| Doba odozvy | 16 (Typ.)(Tr+Td) |
| pozorovací uhol | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| signálové rozhranie | eDP (1 Lane), 30 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NOPC |
