| Číslo dielu | B070ATN02.0 |
| Značka | AUO |
| Veľkosť | 7.0 |
| Aplikácia | PAD |
| Rozhodnutie | 600×1024 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 500:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | AUO |
| panelový model | B070ATN02.0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 600(RGB)×1024 , WSVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 89.28×152.37 mm |
| obrys | 96.98×163.82×4.25 mm |
| povrch | |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193150% |
| Doba odozvy | 8 (Typ.)(Tr+Td) |
| pozorovací uhol | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 3S6PWLEDWithout Driver |
| signálové rozhranie | MIPI (4 data lanes), 32 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
