| Číslo dielu | AL2004A |
| Značka | Other |
| Veľkosť | 3.0 |
| Aplikácia | |
| Rozhodnutie | 20×4 |
| Zloženie | OLED |
| Jas | |
| CR | |
| Farby | Mono(White) |
| Podsvietenie | self |
| Rozhranie | CPU |
| značka panelu | Amson |
| panelový model | AL2004A |
| typ panelu | PM-OLED , OLED |
| veľkosť panelu | 3.0 inch |
| formát zobrazenia | 20 characters × 4 lines |
| zobraziť fonty | 5×7 dots + cursor |
| veľkosť postavy | 2.97×4.77 mm |
| rozstup znakov | 3.55×5.35 mm |
| aktívna oblasť | 70.42×20.82 mm |
| oblasť rámu | 72.42×22.82 mm |
| obrys | 98×60×9.7 mm |
| jas | |
| kontrastný pomer | |
| zobraziť farby | Mono(White) |
| vodič ic | Built-in KS0066 |
| signálové rozhranie | 8-bit parallel, 16 pins |
| vstupné napätie | 3.3V (Typ.) |
